2 Recipe Function Configuration Procedure
18-4 WindO/I-NV4 User’s Manual
This section describes the configuration procedure for the Recipe function.
2.1 Configuring Recipe Function Operations and Device Addresses
1 On the Configuration tab, in the System Setup group, click Recipe.
The Recipe Settings dialog box is displayed.
2 Specify the number of blocks to use as data for the recipe in Number of Blocks.
The operation using the data for the recipe is configured in blocks (0 to 64). 1 channel is used for 1 item of data for
the recipe. 1 block is 16 channels.
The maximum number of blocks that can be configured is 64 blocks. The maximum number of device addresses that
can be configured for 1 channel is 8192 devices.
3 Select the number of the data for the recipe to configure in Settings, then click Edit.
The Individual Settings dialog box is displayed.
2 Recipe Function Configuration Procedure
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P
