WindO/I-NV4 User’s Manual 8-139
7 Keypad
8
Buttons
7.1 How the Keypad is Used
A part comprised of Key Buttons. Enters numbers and characters into Numerical or Character Input parts.
• Entering numbers in the Numerical Input
• Entering characters in the Character Input
7Keypad
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P
1230
MICRO/I
Numerical Input
Keypad
MICRO/I
Character Input
Keypad
Do not use the Keypad part with the Goto Screen Button or a combination of Goto Screen Commands. For
details, refer to “5 Key Button” on page 8-72.
