3 Goto Screen Button
8-40 WindO/I-NV4 User’s Manual
3.2 Goto Screen Button Configuration Procedure
This section describes the configuration procedure for Goto Screen Buttons.
1 On the Home tab, in the Parts group, click Buttons, and then click Goto Screen Button.
2 Click a point on the edit screen where you wish to place the Goto Screen Button.
3 Double-click the dropped Goto Screen Button and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Trigger Condition tab and Options tab only appear in Advanced mode.
