2.1 How the Multi-State Lamp is Used
Multi-state lamp parts display drawing objects. The value of a specified word device is used to switch the drawing
object to be displayed.
• Switch and display pictures by values of device addresses
2 Multi-State Lamp
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P
External device
MICRO/I
D0
bit15 bit0
bit3
D0= 0100
bit0
bit3
D0= 0001
bit0
bit3
D0= 0010
bit0
bit3
D0= 0000
bit0
bit3
State:
0
State:
1
State:
2
OFF
(None)
