WindO/I-NV4 User’s Manual 8-161
9 Potentiometer
8
Buttons
9.2 Potentiometer Configuration Procedure
This section describes the configuration procedure for Potentiometer parts.
1 On the Home tab, in the Parts group, click Buttons, and then click Potentiometer.
2 Click a point on the edit screen where you wish to place the Potentiometer.
3 Double-click the dropped Potentiometer and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Trigger Condition tab and Options tab only appear in Advanced mode.
