5 Key Button
8-74 WindO/I-NV4 User’s Manual
5.2 Key Button Configuration Procedure
This section describes the configuration procedure for Key Buttons.
1 On the Home tab, in the Parts group, click Buttons, and then click Key Button.
2 Click a point on the edit screen where you wish to place the Key Button.
3 Double-click the dropped Key Button and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Trigger Condition tab and Options tab only appear in Advanced mode.
