WindO/I-NV4 User’s Manual 13-31
4 Using Data and Detected Alarms
13
Alarm Log Function
4.1 Displaying Saved Data with the Alarm Log Display
1 On the Configuration tab, in the System Setup group, click Alarm Log.
The Alarm Log Settings dialog box is displayed.
2 Select the type of device address to monitor under Source Device Address Type on the Channel tab and specify
Number of Blocks.
3 Select the channel number to register and click Edit.
The Individual Settings dialog box is displayed.
4 Specify the device address to monitor in Source and select Store under Data.
4 Using Data and Detected Alarms
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
To Next Page
