WindO/I-NV4 User’s Manual 29-33
3 File Copy Function
29
Data Transfer Function
3.4 Using File Manager on the MICRO/I to Transfer Project Data
1 Insert an external memory device in the MICRO/I.
2 Press the upper-left edge of the MICRO/I screen for three seconds or more.
The maintenance screen is displayed.
3 Press System Mode.
MICRO/I displays the Top Page in the System Mode.
4 Press Main Menu.
The main menu is displayed.
HG3G HG2G-5F HG4G
HG5G-V HG4G-V HG3G-V HG2G-V
MICRO/I
USB flash drive
SD memory card
External Memory Device
Press and hold
3 or more seconds
HG3G HG2G-5F HG4G
HG5G-V HG4G-V HG3G-V HG2G-V
MICRO/I
Maintenance
System Mode
Device Monitor
Adjust Brightness
When downloading a project configured with security to the MICRO/I, the password screen is displayed.
Select a user name and enter its password. For details, refer to Chapter 23 “User Accounts and the Security
Function” on page 23-1.
Run Offline Main Menu
<< >>
BRIGHTNESS 31
MAC Address 00:03:7B:F0:12:A8
IP Address 192.168.0.1(DHCP)
2010/OCT/14/THU 14:56:44
IDEC HG G SERIES
SYSTEM MODE TOP PAGE
ENG/JPN
