2 HG4G/3G, HG2G-5F
35-32 WindO/I-NV4 User’s Manual
■ HG2G-5F (5.7inch)
Unit: mm
# The size to the expansion module installation side
<Cable Attached Dimensions>
Depending on the type of connection cable used the dimensions shown above will change.
The dimensions given here are representative values and are intended for reference only.
33.6 #
120.0
134.7
54.4
5.0
167.2
152.5
55
40
40
49.4
35
152.5
40
120.0
50
