3 Data Log Settings Dialog Box
14-14 WindO/I-NV4 User’s Manual
■ Edit
Registers or changes the settings for the selected channel number.
Select a channel number and click this button to display the Individual Settings dialog box. The settings for the
selected channel are reflected in the Individual Settings dialog box.
For details, refer to “3.2 Individual Settings Dialog Box” on page 14-16.
■ Up
Shifts the selected settings upward in the list.
■ Down
Shifts the selected settings downward in the list.
■ Clear All Log Data
Select this check box to erase the all log data saved in the data storage area.
■ Number of Stored Data for Data Log per Device Address
Shows the maximum amount of data storage per device address for Data Log data saved in the data storage area. If
data is saved up the maximum amount and then the maximum is exceeded, the old data is deleted and the new data
is saved.
The default is 1024.
Click to display the Data Storage Area Management dialog box where you can change the allocation of data
storage area memory. For details, refer to Chapter 16 “Data Storage Area” on page 16-1.
Range: Shows the time in seconds (1 to 9999) to sample data in a fixed interval when Fixed Period is
selected in Condition of Writing to Data Storage Area. Double clicking the cell displays the
Individual Settings dialog box where you can edit the settings. For details, refer to “3.2
Individual Settings Dialog Box” on page 14-16.
Shows the device address that is the condition of writing to Data Storage Area when Event Bit
or Event Word is selected in Condition of Writing to Data Storage Area. Double clicking
the cell displays the Tag Editor where you can edit the device address. For the device address
configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-68.
Monitor: Shows the write destination device address when monitor count of writings to Data Storage
Area. Shows No when not monitoring. Double clicking the cell displays the Individual Settings
dialog box where you can edit the settings. For details, refer to “3.2 Individual Settings Dialog
Box” on page 14-16. This option can only be set when Enable is selected in Log Function.
Batch: Shows the trigger device address that triggers batch output when batch outputting all the data
saved in the data storage area to the external memory device. Shows No when there is no batch
output. Double clicking the cell displays the Individual Settings dialog box where you can edit
the settings. For details, refer to “3.2 Individual Settings Dialog Box” on page 14-16.
Real Time: Shows whether or not to perform real time output. Double clicking the cell switches between
Yes and No. Data is output to the external memory device in 3 minute intervals for Yes
channels. This option can only be set when Enable is selected in Log Function.
Words: Shows the total number of words of the device addresses that will be sampled by the channel.
Double clicking the cell displays the Individual Settings dialog box where you can edit the
settings. For details, refer to “3.2 Individual Settings Dialog Box” on page 14-16. This option can
only be set when Enable is selected in Log Function.
(Trigger Device Address): Specifies the bit device or the bit num
ber of the word device that trigger
s the erasure of
the data. The data for all channels is erased when the value of the configured device
address changes from 0 to 1. For the device address configuration procedure, refer to
Chapter 2 “5.1 Device Address Settings” on page 2-68.
To Next Page
