1: G ENERAL I NFORMATION
1-12 FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE U SER ’ S M ANUAL FC9Y-B1722
Communication Ports, Serial Port 1, Communication Cartridge 1 and 2 Corresponding Table
The communication ports that are used in serial communication support the following communication interfaces.
*1 Can be used as port 1 for RS232C communication or RS485 communication.
To use, configure the interface under Communication Port in Function Area Settings.
*2 Can be used as port 2 by installing the RS232C communication cartridge (FC6A-PC1) or the RS485 communication cartridge (FC6A-PC3).
*3 Can be used as port 3 by installing the RS232C communication cartridge (FC6A-PC1) or the RS485 communication cartridge (FC6A-PC3).
*4 Cannot be set to "Data Bits: 7 bits" and "Parity: None".
Notes:
• For the locations of serial port 1, cartridge slot 1, and cartridge slot 2, see "Part Names and Functions" on page 2-2.
• For serial port 1 wiring, see "Other Inputs and Ports" on page 2-35. For communication cartridge wiring, see "Terminal Arrangement and
Wiring Examples" on page 2-96.
Type No.
Serial Port
Port 1 Port 2 Port 3
FC6A-C16R1AE
Serial Port 1
*1
Cartridge Slot 1
communication cartridge
*2 *4
No supported communication
interface
FC6A-C16R1CE
FC6A-C16K1CE
FC6A-C16P1CE
FC6A-C24R1AE
FC6A-C24R1CE
FC6A-C24K1CE
FC6A-C24P1CE
FC6A-C40R1AE
Cartridge Slot 2
communication cartridge
*3 *4
FC6A-C40R1CE
FC6A-C40K1CE
FC6A-C40P1CE
FC6A-C40R1DE
FC6A-C40K1DE
FC6A-C40P1DE
FC6A-C40R1AEJ
No supported communication
interface
FC6A-C40R1CEJ
FC6A-C40K1CEJ
FC6A-C40P1CEJ
FC6A-C40R1DEJ
FC6A-C40K1DEJ
FC6A-C40P1DEJ
