Uploading the User Program (CPU module –> SD memory card)
Upload the user program on the CPU module to the SD memory card.
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select External Memory with the (up) and (down) buttons and press the (OK) button.
3. Select SD Card with the (up) and (down) buttons and press the (OK) button.
4. Select Program with the (up) and (down) buttons and press the (OK) button.
5. Select Upload with the (up) and (down) buttons and press the (OK) button.
6. Enter the file name to create by the upload with the (up), (down), (left), and (right) buttons and press the
(OK) button.
*1
*1 The file name that can be entered is between one and eight characters in length. The file name is the entered value from the beginning to the
space. The uploaded file is stored in the PROGRAM folder on the SD memory card.
7. The screen below is displayed while the user program is uploaded. When the upload is finished, the screen in step 4 is
displayed.
Stopped
2015/DEC/01/TUE
13:30:40
Run
Edit Program
External Memory
Configurations
Stop Access
Format
Recipe
Program
To Next Page
Loading...
