FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE U SER ’ S M ANUAL FC9Y-B1722 9-7
9: F UNCTIONAL M ODULES
(5) Sample Time
Analog values are converted to digital values at the interval of the sampling duration time. Depending on the analog module,
you may be able to change the sample duration time setting.
(6) Thermistor settings
When NTC thermistor is selected for the FC6A-J8CU1 signal type, the following parameters must be set.
(7) Data
Data refers to the input analog values converted to digital values at the interval of the sampling duration time.
The data is written to data registers in the END processing of each scan. The analog input data is updated regardless of whether
the FC6A Series MicroSmart is stopped or running. The data is not guaranteed when the status (8) is a value other than "0".
Type Signal Type Sample Time
FC6A-J2C1
0 to 10 V 1 ms
-10 to +10 V 1 ms
0 to 20 mA 1 ms
4 to 20 mA 1 ms
FC6A-J4A1
0 to 10 V 1 ms/10 ms
-10 to +10 V 1 ms/10 ms
0 to 20 mA 1 ms/10 ms
4 to 20 mA 1 ms/10 ms
FC6A-J8A1
0 to 10 V 1 ms/10 ms
-10 to +10 V 1 ms/10 ms
0 to 20 mA 1 ms/10 ms
4 to 20 mA 1 ms/10 ms
Expansion 0 to 20 mA 1 ms/10 ms
Expansion 4 to 20 mA 1 ms/10 ms
FC6A-J4CN1
0 to 10 V 100 ms/10 ms
-10 to +10 V 100 ms/10 ms
0 to 20 mA 100 ms/10 ms
4 to 20 mA 100 ms/10 ms
Thermocouple 104 ms
Resistance thermometer 104 ms
FC6A-J8CU1
Thermocouple 104 ms
NTC/PTC thermistor 104 ms
PTC thermistor (threshold) 104 ms
Resistance measurement 104 ms
FC6A-L06A1
0 to 10 V 1 ms/10 ms
-10 to +10 V 1 ms/10 ms
0 to 20 mA 1 ms/10 ms
4 to 20 mA 1 ms/10 ms
FC6A-L03CN1
0 to 10 V 100 ms/10 ms
-10 to +10 V 100 ms/10 ms
0 to 20 mA 100 ms/10 ms
4 to 20 mA 100 ms/10 ms
Thermocouple 104 ms
Resistance thermometer 104 ms
Parameter Description Range
R0 The thermistor resistance in "T0"°C 0 to 65,535
T0 Temperature -32,768 to 32,767
B Thermistor B constant -32,768 to 32,767
