2: P RODUCT S PECIFICATIONS
2-32 FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE U SER ’ S M ANUAL FC9Y-B1722
(2) Input terminals
DC Sink Input Wiring
DC Source Input Wiring
(3) Output terminals
Relay Output: FC6A-C24R1CE
Transistor Sink Output: FC6A-C24K1CE
Transistor Protection Source Output: FC6A-C24P1CE
24-I/O type: FC6A-C24R1CE, FC6A-C24K1CE, FC6A-C24P1CE
(1) Power supply terminals
(2)
(3)
(1)
: Fuse
: Load
L
+24V - FE
24V DC Power Input
- +
External Power
24V DC
NC. NC.
–
COM I0 I1 I2 I3 I4 I5 I6 I7 I10 I11 I12 I13 I14 I15
24V DC Input 24V DC Input
-
+
-
+
External Power
24V DC
2-wire
Sensor
NC.
NC. COM
I0 I1 I2 I3 I4 I5
I6
I7 I10 I11 I12 I13 I14 I15
– 24V DC Input 24V DC Input
+
-
+
-
External Power
24V DC
2-wire
Sensor
I10
I11 COM2
Relay Output
Q0
Q1 Q2 Q3 COM1COM0 Q4 Q5 Q6 Q7
LLLL
-
+
Transistor Sink Output (24 V)
Q1
Q2 Q3 Q4 Q5Q0 Q6 Q7 COM0(-)COM0(-) V0(+)
I11
I10
L L L L L L L LLL
+
-
Transistor Protection Source Output (24 V)
Q1
Q2 Q3 Q4 Q5Q0 Q6 Q7 COM0(+)COM0(+) V0(-)
I11
I10
L L L L L L L LLL
-
+
