Appendix Library ACnnnn_Utils.library
Image of the projected
configuration data
(PCD = Projected Configuration
Data)
Each word contains data of one slave:
Bits 0...3 = IO
Bits 4...7 = ID
Bits 8...11 = ID1
Bits 12...15 = ID2
→ DS12 – Projected configuration data (PCD)
Input parameters of the S/A slaves
Each byte contains parameters of one S/A
slave:
Bits 0...3 = P0-P3
Bits 4...7 = reserved
→ DS13 – Image of the input parameters of the
slaves (PI), words 0...15
Input parameters of the B slaves
Each byte contains parameters of one B
slave:
Bits 0...3 = P0-P3
Bits 4...7 = reserved
→ DS13 – Image of the input parameters of the
slaves (PI), words 16...31
Output parameters of the S/A
slaves
Each byte contains parameters of one S/A
slave:
Bits 0...3 = P0-P3
Bits 4...7 = reserved
→ DS14 – Image of the output parameters of the
slaves (PP), words 0...15
Output parameters of the B slaves
Each byte contains parameters of one B
slave:
Bits 0...3 = P0-P3
Bits 4...7 = reserved
→ DS14 – Image of the output parameters of the
slaves (PP), words 16...31
>
ASI_NET (STRUCT)
15993
The structure contains the complete process image (inputs and outputs) of an AS-i network.
Binary input and output data
→ ASI_BIN_IO (STRUCT) (→ p. 117)
Analogue input and output data
→ ASI_ANA_IO (STRUCT) (→ p. 118)
-
>
ASI_BIN_IO (STRUCT)
16002
The structure contains the process data of the digital input and output slaves:
Input data of the digital AS-i slaves
→ ASI_BIN_IN (STRUCT) (→ p. 118)
Output data of the digital AS-i
slaves
→-ASI_BIN_OUT (STRUCT) (→ p. 118)
