Ihse Draco User Manual

Draco KVM Extender
14 2011-03-09
3.6.4 Model K477-1S4MA / -1S4SA (Analog Audio / Serial)
CPU Unit CON Unit
6 7 8
1
2
3
4
5
9
6 7 8
9
1
2
3
4
5
Rear View Rear View
1 Connect to 5VDC power
supply
2 Service port
3 Connect to interconnect cable
4 To CPU: USB-HID 1
5 To CPU: DVI-D
6 Connect to serial (D-Sub 9)
7 Audio IN
8 Audio OUT
9 To CPU: USB-HID 2
1 Connect to 5VDC power
supply
2 Service port
3 Connect to interconnect cable
4 Connect to USB-HID devices 1
5 Connect to DVI-Monitor
6 Connect to serial (D-Sub 9)
7 Audio IN
8 Audio OUT
9 Connect to USB-HID devices 2
