Ihse Draco User Manual

Description
2011-03-09 15
3.6.5 Model K477-1S4CD (Digital Audio)
CPU Unit CON Unit
9
1
2
3
4 5
6
8
7
6
8
7
9
1
2
3
4
5
Rear View Rear View
1 Connect to 5VDC power
supply
2 Service port
3 Connect to interconnect cable
4 To CPU: USB-HID 1
5 To CPU: DVI-D
6 RCA input
7 Mini-XLR input
8 TOSLINK input
9 To CPU: USB-HID 2
1 Connect to 5VDC power
supply
2 Service port
3 Connect to interconnect cable
4 Connect to USB-HID devices 1
5 Connect to DVI monitor
6 RCA output
7 Mini-XLR output
8 TOSLINK output
9 Connect to USB-HID devices 2
Pos: 15 /806-IHSE/Besc hreibung/Gerätea nsichten/477- xx_COMP/1S4MD / -1S4SD (mit Di gital-Audio) @ 5\mod_12 91647770271_6.doc @ 45874 @ 3
