Description
2011-03-09 9
3.2 System Overview
The KVM Extender consists of a CPU Unit and a console unit (CON Unit).
The CPU Unit is connected directly to the source (computer, CPU) using
the supplied cables.
The CON Unit is connected to the console (monitor, keyboard and
mouse).
The CPU Unit and the CON Unit communicate with each other through the
interconnect cables.
1
2
4
5
7
6
3
System Overview
1 Source (computer, CPU)
2 KVM Extender CPU Unit
3 Interconnect cable
4 KVM Extender CON Unit
5 Console (monitor, keyboard, mouse)
6 Second monitor (option, only with Dual-Head devices)
7 USB-HID devices (option, only with 4x USB-HID devices)
See Chapter 4.3, Page 32 for installation examples.
