Other USB-HID devices
The proprietary USB emulation also supports certain other USB-HID
devices, such as specific touch screens, graphic tablets, barcode
scanners or special keyboards. Support cannot be guaranteed, however,
for every USB-HID device.
Only two USB-HID devices are supported concurrently, such as keyboard
and mouse or keyboard and touch screen. A hub is allowed, but it does
not increase the number of HID devices allowed.
To support other USB 'non-HID' devices, such as scanners, web cams or
memory devices, choose our devices with transparent USB support.
Pos: 40 /806-IHSE/ Technische Daten/Schni ttstellen/USB 2.0 ( transparent) @ 5\mod_1278 578316386_6.doc @ 42168 @ 3
7.1.4 USB 2.0 (transparent)
KVM Extender models with transparent USB 2.0 support allow the
connection of all types of USB 2.0 devices (without restriction). USB 2.0
data transfer is supported with USB high speed (max. 480 Mbit/s).
Each USB 2.0 port provides a maximum current of 500 mA (high power).
Pos: 41 /806-IHSE/ Technische Daten/Schni ttstellen/RJ45 (Ger ätekommunikation) @ 5\ mod_1278578339308_6. doc @ 42186 @ 3
7.1.5 RJ45 (Interconnect)
The communication of the Cat X devices requires a 1000BASE-T
connection.
Connector wiring must comply with EIA/TIA-568-B (1000BASE-T), with
RJ45 connectors at both ends. All four cable wire pairs are used.
Pos: 42 /806-IHSE/ Technische Daten/Schni ttstellen/Glasfaser SFP Typ LC @ 5\mod_127893770 0855_6.doc @ 43149 @ 3
7.1.6 Fiber SFP Type LC (Interconnect)
The communication of fiber devices is performed via Gigabit SFPs that
have to be connected to suitable fibers fitted with connectors type LC (see
Chapter 7.2.2, Page 43).
The correct function of the device can only be guaranteed with SFPs
provided by the manufacturer.
SFP modules can be damaged by electrostatic discharge (ESD).
When handling, care must be taken so that the devices are not damaged.
