Specifications
2011-03-09 41
7.1.9 Digital Audio Interface
The digital audio option supports the unidirectional transmission of digital
audio data.
Up to three sources can be connected to the CPU Unit. The active source
is transmitted. If several sources are active, the XLR signal takes priority,
otherwise the first active signal.
Up to three sinks can be connected to the CON Unit. The signal is
available at all outputs concurrently.
Compatibility
AES-3, S/PDIF, EIAJ CP1201, IEC-60958
Standards
Dolby Digital, DTS, PCM
Scanning Frequency
32 to 48 kHz
CPU Unit (Inputs)
 Mini-XLR (symmetrical, lockable)
 Coaxial (RCA, Cinch)
 Optical (TOSLINK)
CON Unit (Outputs)
 Mini-XLR (symmetrical, lockable)
 Coaxial (RCA, Cinch)
 Optical (TOSLINK)
