Page #31 background imageLoading...
Page #31 background image
Installation
2011-03-09 31
4.2.2 Setup of Optional Modules
The modules can be hot plugged.
Analog Audio / Serial Option:
1. Connect the audio source with the CPU Unit (e.g. CPU audio output
with audio input, CPU audio input with audio output).
2. Connect the audio output at the CON Unit with headphones or
suitable speakers.
3. Connect the audio input at the CON Unit with a suitable microphone.
Digital Audio Option:
1. Connect the digital audio source with the suitable audio input of the
CPU unit.
2. Connect the audio output of the CON Unit with suitable speakers or
audio amplifiers.
If several active sources are connected, Mini-XLR input takes priority.
The audio signal is available at all outputs.
USB-HID Add-On Option:
1. Connect the CPU with the CPU Unit (USB-HID 2).
2. Connect the USB-HID devices with the CON Unit (Connect to
USB-HID devices 2).
USB 2.0 Add-On Option:
1. Connect the CPU with the CPU Unit (USB 2.0).
2. Connect the USB 2.0 devices with the CON Unit (Connecto to
USB 2.0 devices).
Pos: 26 /806-IHSE/Ins tallation/Insta llationsbeispiel e/UEB_Installatio nsbeispiele @ 5\mod_127 8581564870_6.doc @ 42759 @ 2
