A Hardware Setup
A.1 Content on Delivery
The Bookeye® 3 scanner is delivered in a wooden transport box.
Picture 1: Transport box
The transport box contains all components of the scanner. These are
• the two lamps,
• the camera neck,
• the glass plate,
• a cardboard box containing the camera head and the integrated short part of the
camera neck,
• the accessory boxes and
• the reference folder with some test targets.
Please note: Keep the wooden transport box and the cardboard box for future use!
For warranty returns, the scanner must be sent back in the original
transport box to avoid transport damages.
The crates and the inserts have been designed and tested to withstand all impacts, in
accordance with the internationally recognized test procedure ISTA-1B for packages over
150lbs or 68kg. Details can be found at http://www.ista.org/Testing/Tests.htm
.
This requires that the packaging instructions are followed precisely. One common mistake
made is that additional parts are put in the side pockets formed between the crate and the
PE- inserts. This space must be free of obstacles in any case; because in the case of an
impact, the inserts will compress to 40% of their original size and the free space will be
used up completely.
Page 12 Setup and Assembly Manual
