Image Access bookeye 3 Assembly Manual

The two screw head caps at the upper end of the lamp arm help to set the light beam to
the best position.
Picture 44: Light beam adjusted
A.2.4.2 Saving the lamp positions
Press the green START button to save both lamp positions.
The sound “OK” will be played and the display shows
Saving new positions
The lamp positions will also be saved automatically when the time out period has passed
without any activity.
A.2.4.3 Leaving the initialization mode without saving
Press the red STOP button to leave the initialization mode. The lamp positions will not be
saved.
Setup and Assembly Manual Page 37
