2. Take off the round metal plate by removing the two brass nuts.
3. Loosen the screw of the die-cooler from the left side with the Allen key.
Figure 38: die cooler
4. Remove "old" crucible, die and, if necessary, drawing roller.
5. Check the crucible and the die for scratches.
For wire dies we can offer you conical reamers to recondition the surface.
Check for the code C179 in our Webshop.
Figure 39: conical reamer
The crucible and the die must be glued together with the use of liquid
graphite #15000020 called Hydrokollag.
Figure 40: Hydrokollag
Insert now the crucible and the die as one package:
6. Tighten the die-cooler again.
7. Install the round metal plate but don’t tighten.
