InFocus IN5122 User Manual

31
PICTURE menu
Item Description
COLOR
TEMPERATURE
Using the ▲/▼ buttons switches the color temperature mode.
1 HIGH

1 CUSTOM

2 MID

2 CUSTOM
3 LOW
5 CUSTOM

5 Hi-BRIGHT-2

4 CUSTOM

4 Hi-BRIGHT-1
6 CUSTOM



6 Hi-BRIGHT-3

3 CUSTOM
To adjust CUSTOM
Highlighting a CUSTOM mode and then
pressing the ► or the SELECT button
will display a dialog to help you adjust the
OFFSET and GAIN of the selected mode.
OFFSET adjustments change the color intensity of the test pattern's
whole tones.
GAIN adjustments mainly affect color intensity on the test pattern's
brighter tones.
Choose an item using the ◄/► buttons, and adjust the level using
the ▲/▼ buttons.
You can display a test pattern to check your adjustments by pressing
the SELECT button.
Each time you press the SELECT button, the pattern changes as below.
No pattern
ð
Gray scale of 9 steps
Ramp

Gray scale of 15 steps
• Lines or other noise may appear on the screen
when this feature is operated, but this is not a
malfunction.
COLOR
Using the ◄/► buttons adjusts the strength of whole color.
Weak
ó
Strong
• This item can only be selected for a video, S-video and component
video signal.
•
For an HDMI™ signal, this item can also be selected if either (1) or (2) ap-
plies.
(1) HDMI FORMAT has been set to VIDEO in the INPUT menu.
(2) HDMI FORMAT has been set to AUTO in the INPUT menu, and
the projector recognizes the HDMI™ video signal.
TINT
Using the ◄/► buttons adjusts the tint.
Reddish
ó
Greenish
• This item can only be selected for a video, S-video and component
video signal.
•
For an HDMI™ signal, this item can also be selected if either (1) or (2)
applies.
(1) HDMI FORMAT has been set to VIDEO in the INPUT menu.
(2) HDMI FORMAT has been set to AUTO in the INPUT menu, and
the projector recognizes the HDMI™ video signal.

InFocus IN5122 Specifications

General

Matrix size	0.63 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	35.4 - 358 \
Projector native resolution	XGA (1024x768)
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	106 kHz
Horizontal synchronization (min)	15 kHz
Focus	Manual
Throw ratio	1.5 - 2.5:1
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	-20 - 0 °
Horizontal lens shift range	-20 - 20 %
Lamp type	UHP
Lamp power	245 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
3D	-
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1600 x 1200 (UXGA)
RMS rated power	16 W
Number of built-in speakers	2
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Cables included	AC, RCA, VGA
Power consumption (standby)	- W
Noise level	32 dB
Certification	UL, c-UL, FCC, CE
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Operating altitude	0 - 2286 m
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	318.5 mm
Width	401 mm
Height	111 mm
Weight	4800 g
Package depth	420 mm
Package width	560 mm
Package height	197 mm
Package weight	8200 g
