LP500 Series Service Manual 67
6 Remove the elevator lever and spring through the hole in the bottom case.
Assembly Note
♦ Install the elevator assembly first, then the light block louver. Align the two holes on the engine mount
spacer with the two registration pins on the bottom case, then torque the M3x8 Plastite Torx screw to
6 in/lbs (.68 Nm).
