p16 Section 2. Intro. Version 1.01 CONCEPT IQ. Installation & Programming Manual.
18. IF the Re-Autoarm function is required, program a Re-Autoarm time.
Address 871.
NOTE: If a Pre-arm warning is required, program the “Autoarm Pre-warn time”. Address 870.
19. IF the system has Access Control via one or more Enhanced Terminals, program the Door Times.
-Program the Door Unlock time. Address 872 (Default is 5 Seconds)
20. IF the system is to report in Contact ID or Domestic Dialer formats, program the Dialer options.
-Program the Primary & Secondary Telephone numbers. Addresses 16 and 32.
-Select the Reporting Format. 1 = Contact ID. 2 = Domestic. Address 48.
-Select the required Dialer Options. Address 49.
1 Alarms reported via Dialer. 5 Openings reported only after an alarm.
2 Restores reported via Dialer. 6 Remote control via DTMF Card enabled.*
3 Area Open/Close reported via Dialer. 7 Isolates reported via Dialer.
4 Programming change reported via Dialer.
* DTMF Card must be fitted to Control Module.
-Edit the maximum dial attempts if required. (Default = 10 attempts) Address 50.
-Program the Client Code/s. Area 1 only if system is programmed for Single Area operation.
Address 896: Area 1 Address 904: Area 3
Address 900: Area 2 Address 908: Area 4
21. IF periodic Test Reports are to be sent to the Central Monitoring Station, program the Test Report options.
-Program the Test Report period. Address 51.
0 No Test Report. 2 Every Monday.
1 Every Day. 3 First day of every Month.
-Program the time of day the Test Report is to be sent. Address 52: Hour. Address 53: Minute.
22. IF Remote connection for Upload/Download or Telephone is required, program the Remote Connect options.
-Program the Remote Connect Options. Address 54
0 = No Remote connect. 1 = Remote Connect allowed. 2 = Remote connect with Callback.
-Program the number of rings before answer. Address 80.
-IF Answering machine (Fax machine) bypass is required, program the “Follow-on” time.
Address 81. (See Section 10 [Communications] for details)
-IF the “Remote connect with Callback” option was selected, program a “Callback Telephone no”. Address 64.
23. IF the Serial Port on the Control Module is to be used, program the Serial Port options.
-Select the Communications Task. Address 82. 3 = Upload / Download.
-Select the Baud Rate. (Default is 9600) Address 83 0 = 300. 1 =1200. 2 = 4800. 3 = 9600
24. Change the Installer PIN code.
Address 96. This should be done before the system is commissioned and handed over to the client.
Ensure that a new PIN code is chosen that will not be forgotten, while still providing security against unauthorised
access.
25. Program the Users.
A Master User Code must be used to program the Users. See the User’s Manual for details.
