Section 8. Auxiliaries. Version 1.01 p1CONCEPT IQ. Installation & Programming Manual.
Auxes
0 User (Master) Control/Test Only. (via NEXT 24)
1 Burglary Alarm. Default for Auxiliary 1. (Strobe)
2 Fire Alarm
3 Area 1 Armed In Normal Mode
4 Area 2 Armed In Normal Mode
5 Area 3 Armed In Normal Mode
6 Area 4 Armed In Normal Mode
7 Area 1 Armed In Home Mode
8 Area 2 Armed In Home Mode
9 Area 3 Armed In Home Mode
10 Area 4 Armed In Home Mode
11 Spare
12 Spare
13 Spare
14 Spare
15 Entry Timer - General Area / Area 1
16 Exit Timer - General Area / Area 1
17 Zone 1 in Alarm *
18 Zone 2 in Alarm *
19 Zone 3 in Alarm *
20 Zone 4 in Alarm *
21 Zone 5 in Alarm *
22 Zone 6 in Alarm *
23 Zone 7 in Alarm *
24 Zone 8 in Alarm *
25 Zone 9 in Alarm *
26 Zone 10 in Alarm *
27 Zone 11 in Alarm *
28 Zone 12 in Alarm *
29 Zone 13 in Alarm *
Section 8. Auxiliary Output Programming
Auxiliary Event Type..................................................................................................................................1
Auxiliary Timers .........................................................................................................................................2
Auxiliary Response....................................................................................................................................2
Auxiliary Event Type details ......................................................................................................................3, 4
These Addresses set the programming options for the ten Auxiliaries AUXILIARY 1 to AUXILIARY 10.
Each Auxiliary has 3 Addresses related to the programming.
AUXILIARY EVENT TYPE
The Auxiliary Event Type detemines which Entity or Event will the control the Auxiliary.
To define the way in which the Auxiliary is controlled, the “Auxiliary Response” must also be programmed.
Auxiliary Number: 1 2 3 4 5 6 7 8 9 10
Event Type Address: 816 817 818 819 820 821 822 823 824 825
Summary of Auxiliary Event Types.
For a full explanation of Auxiliary Event Types refer to the table at the end of this section.
Address
816 to 825
832 to 841
848 to 857
816
to
825
Data type:
Value
Range:
1 - 59
30 Zone 14 in Alarm *
31 Zone 15 in Alarm *
32 Zone 16 in Alarm *
33 Spare
34 Any “Day Alarm” Zone Unsealed * ^
35 Timezone 1 Valid
36 Timezone 2 Valid
37 Timezone 3 Valid
38 Timezone 4 Valid
39 Any Zone Bypassed (Isolated) on Arming
40 Any System Input in Alarm
41 Door 1 Alarm
42 Door 2 Alarm
43 Door 3 Alarm
44 Door 4 Alarm
45 Area1 Auto Arm Pre-warning
46 Area2 Auto Arm Pre-warning
47 Area3 Auto Arm Pre-warning
48 Area4 Auto Arm Pre-warning
49 Alarm in Area 1
50 Alarm in Area 2
51 Alarm in Area 3
52 Alarm in Area 4
53 Entry / Exit Timer Area 1
54 Entry / Exit Timer Area 2
55 Entry / Exit Timer Area 3
56 Entry / Exit Timer Area 4
57 Smoke Detector Reset *
58 Comms Fail
59 Follow Siren
* These Event Types can only be turned On by the specified Event, and must be turned Off by a Timer.
i.e. Program an Auxiliary Time for the Auxiliary & in the Auxiliary Response Options, do not Enable Option 3.
^ Event Type 34. Event activated whenever Any “Day Alarm” Zone goes Unsealed when the Area that it is
assigned to is Disarmed (Turned Off).
