3 MECHANICAL INSTALLATION
3.1 Compatibility
3.1.1 Hardware Compatibility
3.1.1.1 Machine Mounting
Assuming the suitable bezel (and cashbox) type has been ordered the BV20 can be
used as fitting replacement for the following products:
• BV20
The BV20 may not be used as fitting replacement for the following products:
• BV50
• BV100
• NV150
• NV9 USB
• NV10 USB
• NV200
Innovative Technology Ltd. has a policy of continuous product improvement. Due to
design changes older model or product bezels (and cashboxes) may not be
compatible with the BV20. However, new product deliveries always include a bezel
(and cashbox) that must be used.
Caution!
Only use bezel (and cashbox)
delivered with the product!
3.1.1.2 Machine Interfacing
By design the BV20 is pin to pin compatible with the suitable fitting replacement
products listed above. No changes to existing machine harnessing are required.
3.1.1.3 Power Supply
It is vital that the BV20 is connected to a power supply being able to provide the
required power environment. A weak power supply causes malfunctioning of the
BV20 such like note rejects or missing credits. If the BV20 is used as a fitting
replacement for an older model or product we recommend to check the power
supply specifications of the machine. The power supply of the machine might be
designed for the older model or product but not suitable for the BV20. The BV20
might have higher power consumption. Refer to 9.4 for full power requirement
details of the BV20.
Caution!
A weak power supply causes
malfunctioning!
