2 PRODUCT INTRODUCTION
2.1 General Description
The BV20 is a compact, light-weight bill acceptor ideal for amusement and low value
vending applications. Proven field reliability, quick transactions and easy
maintenance make the unit future proof.
Exceptional value, the BV20 allows a bill acceptor to be installed for the same price
as a coin mech.
2.2 Key Features
• Compact bill acceptor
• Simple design
• Exceptional value
• Ideal for amusement, kiddie rides & jukebox applications
2.3 Typical Applications
• Gaming
• Amusement
• Vending
2.4 Component Overview
Lozenge
release catch
Expansion port
clips
Note path
output
Bezel
Configuration
function button
