GA02118 User Manual BV20
<< Back to Contents
Copyright © Innovative Technology Ltd 2018 Doc: GA02118/1 User Manual BV20
Version: 1.0
Page 33 of 60
5.5.5 Setup Example Drawing/s
For MDB PSU mounting:
1. Clip MDB PSU onto BV20’s External Hardware Clip
16-Pin
Connector
Socket
External
Hardware Clip
External
Hardware Clip
Configuration
button
