9 TECHNICAL DATA
9.1 Dimensions
9.2 Weight
• Validator = 0.3 kg
9.3 Environmental Requirements
Environment
Minimum
Maximum
Temperature
+3°C
+50°C
Humidity
5%
95% Non-condensing
9.4 Power Requirements
9.4.1 Supply Voltages
Supply Voltage
Minimum
Nominal
Maximum
Supply Voltage (V DC)
+ 10.8 V DC
+ 12 V DC
+ 14.2 V DC
Supply Ripple Voltage
0 V
0 V
0.25 V @ 100 Hz
9.4.2 Supply Currents
Supply Current
Maximum
Standby
0.15 A
Running
0.54 A
Peak
1.50 A
