42
Basic Setup
—Continued
Crossover Frequency
Notes:
If the crossover frequency is set to a low value, and the
program material doesn’t contain any sounds that are
below that frequency, accordingly, the subwoofer will
not output much sound.
This procedure can also be performed by using the
DTR-8.4’s [Setup] button, [ ]/[ ]/[ ]/[ ] but-
tons, and [Enter] button.
7
Use the Up/Down [ ]/[ ] but-
tons to select “d. Surround, and
then use the Left/Right [ ]/[ ]
buttons to select:
Small:
Select if the surround left and
right speakers are small.
Large:
Select if the surround left and
right speakers are large.
None:
Select if no surround left and
right speakers are connected.
Note:
If the Front setting in step 5 is set to
Small, the Large option cannot be
selected.
8
Use the Up/Down [ ]/[ ] but-
tons to select “e. Surr Back, and
then use the Left/Right [ ]/[ ]
buttons to select:
Small:
Select if the surround back
left and right speakers are
small.
Large:
Select if the surround back
left and right speakers are
large.
None:
Select if no surround back left
and right speakers are con-
nected.
Notes:
If the Surround setting in step 7 is set
to None, this setting cannot be
selected.
If the Surround setting in step 7 is set
to Small, this setting cannot be set to
Large.
If the Surr Back/Zone2 setting is set
to Zone 2, this setting cannot be
selected (see page 86).
Continue with step 9 in the right col-
umn.
9
Use the Up/Down [ ]/[ ] but-
tons to select “f. Crossover, and
then use the Left/Right [ ]/[ ]
buttons to select a crossover fre-
quency.
Choose a crossover frequency suitable
for your setup. If you’re using a sub-
woofer, choose a crossover frequency
based on the diameter of your front
speakers. If you’re not using a sub-
woofer, use the diameter of any speaker
that you specified as Small.
If you’re using THX-certified speakers,
select 80 (THX).
10
Press the [Setup] button.
The setup menu closes.
Speaker cone
diameter
Crossover
frequency
Over 12 in.
(30 cm)
40Hz
8 to 12 in.
(20–30 cm)
60Hz
6-1/2 to 8 in.
(16–20 cm)
80Hz (THX)
5-1/4 to 6-1/2 in.
(13–16 cm)
100Hz
3-1/2 to 5-1/4 in.
(9–13 cm)
120Hz
Under 3-1/2 in.
(9 cm)
150Hz
DTR-8.4En.book Page 42 Thursday, October 16, 2003 11:09 AM
