Intel 6 SERIES

Quick Start
2
nd
Generation Intel
®
Core™ Processor with Intel
®
6 Series Chipset Development Kit
March 2011 User Guide
Document Number: 325208-001 59
#
Reference
Designator
Description Default Setting
17
J7H1 SATA HOT PLUG (1-2)
18 J8C3 SIO RESET (1-2)
19
J8C6 IN CKT H8 PROGRAMMING (1-2)
20
J8C7 IN CKT H8 PROGRAMMING (1-2)
21
J8G5 H8 MODE SELECTION (1-2)
22 J9H1 VAUX SELECT (1-2)
23
J6G2 VCCP VR VOLTAGE SELECT (1-2)
24
J9G1 BOOT BLOCK PROGRAMING (1-2)
25
J5C5 SA VR (2-3)
26 J9F4 RST SEL (1-2)
27
J8D3 LVDS EN (2-3)
28
J1C6 SVID DATA (CPU, VR) (1-2)
29 J1D3 SVID CLK (CPU, VR) (1-2)
30 J1D7 SVID ALERT (CPU, VR) (1-2)
NOTE: Ensure proper jumper settings before powering-up the board. Please refer to Table 20
for a complete list of jumper settings.
§
