About This Document
2
nd
Generation Intel
®
Core™ Processor with Intel
®
6 Series Chipset Development Kit
User Guide March 2011
8 Document Number: 325208-001
Notation Definition
uppercase or lowercase.
Numbers
Hexadecimal numbers are represented by a string of hexadecimal digits
followed by the character H. A zero prefix is added to numbers that begin
with A through F. (For example, FF is shown as 0FFH.) Decimal and binary
numbers are represented by their customary notations (i.e., 255 is a
decimal number and 1111 is a binary number; in some cases, the letter B
is added for clarity).
Units of Measure
A
Gbyte
Gb
GT
Kbyte
KΩ
mA
Mbyte
MHz
ms
MT
mW
ns
pF
W
V
µA
µF
µs
µW
The following abbreviations are used to represent units of measure:
amps, amperes
gigabytes
gigabits
giga transfers
kilobytes
kilo-ohms
milliamps, mill amperes
megabytes
megahertz
milliseconds
Mega Transfers
milliwatts
nanoseconds
picofarads
watts
volts
microamps, microamperes
microfarads
microseconds
microwatts
Signal Names
Signal names are shown in uppercase. When several signals share a
common name, an individual signal is represented by the signal name
followed by a number, while the group is represented by the signal name
followed by a variable (n). For example, the lower chip-select signals are
named CS0#, CS1#, CS2#, and so on; they are collectively called CSn#.
A pound symbol (#) appended to a signal name identifies an active-low
signal. Port pins are represented by the port abbreviation, a period, and
the pin number (e.g., P1.0).
