Intel EP80579 User Manual

Development Kit User’s Guide
October 2008 Order Number: 320067-002US
27
Technical Reference—Intel
®
EP80579 Integrated Processor with Intel
®
QuickAssist Technology
Figure 10. Side View of the Board Connectors
Table 9. Component and Connector Layout Description (Sheet 1 of 2)
Call-out Component/Connector
AIntel
®
EP80579 Integrated Processor
B PEX PCIe Switch Chip
C Marvell 88E1141 Quad PHY
D Super IO Controller
EFPGA
F Flash memory 0
G Flash memory 1
HFWH
I Power button
J Reset button
K Sleep button
L PCIe Wake button
M Port 80 IC
N CMOS battery
O On-board speaker
P CPU FAN connector
QAUX FAN connector
R AUX0 FAN connector
S AUX1 FAN connector
TATX power connector
U Two 7-segment display (Port 80)
VSATA port 0
WSATA port 1
