4.2 IA-32 Core Frequency Selection
The Intel
®
EP80579 Integrated Processor Product Line is offered in SKUs with a
1200 MHz, 1066 MHz or 600 MHz IA-32 core frequency. The Intel
®
EP80579
Development Board is designed to use the Intel
®
EP80579 Integrated Processor's
V_SEL and BSEL signals to provide the required input clocks and voltages for each of
these IA-32 cores. For Intel
®
EP80579 Integrated Processor SKUs with the 1200 MHz
IA-32 core, V_SEL can be used to force the IA-32 core to run at 1066MHz.
Note: 1200 MHz SKUs can be run at 1066 MHz (but not at 600 MHz).
1066 MHz SKUs can only run at 1066 MHz.
600 MHz SKUs can only run at 600 MHz
Table 10 describes how to configure the Intel
®
EP80579 Development Board to support
the different IA-32 core frequencies.
X DDR2 DIMM0
Y DDR2 DIMM1
Z Slot 0 x8 connector 4 lanes PCI Express
AA Slot 1 x4 connector 1 lane PCI Express
BB Slot 2 x4 connector 1 lane PCI Express
CC Slot 3 x4 connector 1 lane PCI Express
DD Slot 4 x4 connector 1 lane PCI Express
EE Mezzanine connector 1
FF Mezzanine connector 0
GG Floppy Connector
HH CF connector
II ITP-XDP connector
JJ Trusted Platform Module
KK Mezzanine connector 2
MM Parallel port
NN COM0 (Intel
®
EP80579 UART Port 0)
OO COM1 (Intel
®
EP80579 UART Port 1)
PP PS/2 mouse (top)/keyboard (bottom)
QQ USB port 0
RR USB port 1
SS RJ-45 Ethernet port 0
TT RJ-45 Ethernet port 1
UU RJ-45 Ethernet port 2
VV SPI Flash
Table 9. Component and Connector Layout Description (Sheet 2 of 2)
Call-out Component/Connector
