Intel
®
EP80579 Integrated Processor with Intel
®
QuickAssist Technology—Technical Reference
Development Kit User’s Guide October 2008
38 Order Number: 320067-002US
4.8.3 LEB CompactFlash* Connector Pinout
The Intel
®
EP80579 Development Board utilizes the Local Expansion Bus interface that
is connected to the CompactFlash connector and runs in True IDE mode. For more
information, refer to CF+ and CompactFlash Specification Revision 4.0, 5/24/06 for the
standard True IDE mode pinout.
4.8.4 HSS Mezzanine Connectors Pinout
The Intel
®
EP80579 Development Board implements three sets of mezzanine
connectors dedicated to HSS devices. There are two primary cards intended for use
with the Intel
®
EP80579 Development Board, an Intel
®
EPAVM80579 Analog Voice
Mezzanine Card (4-port analog voice card) and a Intel
®
EPTEM80579 Quad T1/E1
Mezzanine Card (quad T1/E1 card). The two cards are different with respect to the
offset of the mezzanine connectors: one is offset left, and the other is offset right.
Each mezzanine card has two 120-pin connectors associated with it. The first connector
is referred to as the standard connector and the second connector is referred to as the
expansion connector. The standard connector includes primary and secondary HSS
interfaces, expansion bus, GPIOs and interrupt. The expansion connectors include SSP
signals, extra GPIOs and 8 expansion bus chip select signals.
Table 17 lists the primary and secondary HSS port numbers in each HSS mezzanine
slot.
The Intel
®
EP80579 Development Board utilizes three GPIO pins to provide interrupts
on the HSS mezzanine connectors. Table 18 provides the GPIO pins that are used as
HSS interrupts.
Table 19 shows the pinout of the standard mezzanine connector. Table 20 provides the
pinout of the expansion mezzanine connector.
Table 17. HSS to Mezzanine Organization
HSS
Mezzanine
Number
Primary
HSS I/F
Secondary
HSS I/F
Natively Supported Card
0 HSS0 HSS1 E1/T1
1 HSS1 HSS0 Dual footprint
2HSS2 E1/T1
Table 18. HSS Interrupt GPIO Pin Names
Pin Name HSS Interrupt Number
GP16_IRQ24 HSS0_INT_OUT
GP17_IRQ25 HSS1_INT_OUT
GP18_IRQ37 HSS2_INT_OUT
Table 19. Standard Mezzanine Connector Pinout (Sheet 1 of 3)
Pin Name Pin Name
1NC 2NC
3NC 4NC
5 EX_DATA_1 6 EX_DATA_0
7 EX_DATA_3 8 EX_DATA_2
To Next Page
