Intel EP80579 User Manual

Development Kit User’s Guide
October 2008 Order Number: 320067-002US
39
Technical Reference—Intel
®
EP80579 Integrated Processor with Intel
®
QuickAssist Technology
9HSSn
1
_GPIO_0 10 HSSn
1
_GPIO_1
11 EX_DATA_5 12 EX_DATA_4
13 EX_DATA_7 13 EX_DATA_6
15 GND 16 GND
17 EX_DATA_9 18 EX_DATA_8
19 EX_DATA_11 20 EX_DATA_10
21 NC 22 NC
23 EX_DATA_13 24 EX_DATA_14
25 EX_DATA_15 26 EX_DATA_16
27 GND 28 GND
29 EX_ADDR_1 30 EX_ADDR_0
31 EX_ADDR_3 32 EX_ADDR_2
33 EX_ADDR_5 34 EX_ADDR_4
35 EX_ADDR_7 36 EX_ADDR_6
37 GND 38 GND
39 EX_ADDR_9 40 EX_ADDR_8
41 EX_ADDR_11 42 EX_ADDR_10
43 EX_ADDR_13 44 EX_ADDR_12
45 EX_ADDR_15 46 EX_ADDR_14
47 GND 48 GND
49 EX_ADDR_17 50 EX_ADDR_16
51 EX_ADDR_19 52 EX_ADDR_18
53 EX_ADDR_21 54 EX_ADDR_20
55 EX_ADDR_23 56 EX_ADDR_22
57 GND 58 GND
59 EX_CLK_HSSn
1
60 EX_RD_N
61 GND 62 EX_WR_N
63 EX_ALE 64 EX_RDY_N
65 EX_IOWAIT_N 66 HSSn
1
_INT_OUT
67 EX_CS_N_i
4
68 3.3V
69 NC 70 3.3V
71 5V 72 3.3V
73 5V 74 3.3V
75 5V 76 3.3V
77 5V 78 3.3V
79 5V 80 3.3V
81 5V 82 3.3V
83 HSSn
1
_GPIO_2 84 HSSn
1
_GPIO_3
85 GND 86 GND
87 HSS_JTAG_TCK 88 HSSn
1
_GPIO_4
Table 19. Standard Mezzanine Connector Pinout (Sheet 2 of 3)
Pin Name Pin Name
