Intel
®
EP80579 Integrated Processor with Intel
®
QuickAssist Technology—Platform Setup
Development Kit User’s Guide October 2008
56 Order Number: 320067-002US
6.0 Platform Setup
This section describes setting up the Intel
®
EP80579 Integrated Processor with Intel
®
QuickAssist Technology Development Kit for operation.
Note: This document assumes that the user is familiar with basic concepts required to install
and configure hardware for a PC system.
The Intel
®
EP80579 Development Board is shipped as an open system attached to an
acrylic base. Some assembly is required. Standoffs are mounted on the acrylic base to
provide flexibility in changing hardware configurations and peripherals, such as is
necessary in a lab environment. Because the board is not enclosed in a protective
chassis, the user must adhere to safety precautions in handling and operating the
Development Board.
6.1 Setting up the Platform
Ensure that all components listed in Section 2.2 arrive together. Once all components
have been identified and located, installation and setup can begin. Figure 17 shows the
basic setup for the Intel
®
EP80579 Development Board (components described by a
green text box are included in the Intel
®
EP80579 Development Kit package.
Components described by a purple text box are optional and are not included in the
Intel
®
EP80579 Development Kit package).
This section describes how to set up the Intel
®
EP80579 Integrated Processor with
Intel
®
QuickAssist Technology Development Kit for operation. All jumpers are set to
their defaults and the platform is ready to boot. See Table 13 for jumper locations and
default settings.
Note: This document assumes that the user is familiar with the basic concepts required to
install and configure hardware for a PC system.
