8.0 Socketed Intel
®
EP80579 Integrated Processor
with Intel
®
QuickAssist Technology Extraction
and Insertion Instructions
8.1 Tools and Preparation
The EP80579 Processor connects to the Intel
®
EP80579 Development Board by a
socket that allows the user to replace the processor with a different EP80579 Processor
SKU. This section provides directions on how to insert and extract the processor.
Caution: Carefully follow these directions, otherwise the processor and platform may
be damaged.
Tools needed:
• Advanced Interconnects Dual-sided Extraction Tool
Or (quantity 2) Advanced Interconnects Single-sided Extraction Tool
•ESD strap
Consumable items needed:
• Disposable towels
• Heatsink thermal grease
