Intermec EasyCoder PF4i Service Manual

Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual 93
Chapter 7—Print Mechanism
FEED
DIRECTION
Dot #0
Dot-line
on printhead
Dot #831
10.3 mm (0.41 in.)
Print Width
max. 104.0 mm (4.095 in.)
Media Width
25-114.3 mm
(
1-4.5 in.
)
8 dots/mm (203.2 dpi) printhead
FEED
DIRECTION
Dot #0
Dot-line
on printhead
Dot #1247
8.6 mm (0.34 in.)
Print Width
max. 105.7 mm (4.161 in.)
Media Width
25-114.3 mm (1-4.5 in.)
11.81 dots/mm (300 dpi) printhead

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
