Thelengthsetupcreatesanemergencystop,whichworkswhenthe
printerissetupfor“Label(wgaps)”,“Ticket(wmark)”,or“Ticket
(wgaps).”Ifthelabelstopsensor(LSS)hasnotdetectedagapor
markwithin150%ofthesetlength,themediafeedisautomatically
stoppedtoavoidfeedingoutawholerollofmedia,becauseofanLSS
malfunction.
BysettinguptheX-start,theWidth,andtheLength,youwillcreatea
printwindowinsidewhichtheprintingcanbeperformed.Anyobjector
fi eldextendingoutsidetheprintwindowinanydirectionwilleitherbe
clippedorcauseanerrorcondition(Error1003“Fieldoutoflabel”),see
IntermecFingerprintv8.xx,Programmer’sReferenceManual .
Print Window (8 dots/mm standard printhead)
10.3 mm (0.41 in)
max.
104.0
mm
(4.095
in)
Length
Dot-line
on
printhead
X-start
FEED
Dot
#0
25-114.3
mm
(1-4.5
in)
