Intermec EasyCoder PF4i - Optional Interfaces

Appendix
C
—
Interfaces
Optional
Interfaces
Theprintercanoptionallybefittedwithoneofthefollowinginterface
boardsattheright-handsideoftheprinter’srearplate:
·DoubleSerialInterfaceBoard(device"uart2:"and"uart3:")
·Serial/IndustrialInterfaceBoard(device"uart2:")
·IEEE1284ParallelInterfaceBoard(device"centronics:")
Regardlessofanyoftheinterfaceboardmentionedaboveisinstalled,the
printercanalsobe
fi
ttedwithoneofthefollowingEasyLANinterface
boardsforconnectiontoaLocalAreaNetwork(LAN):
·EasyLANEthernetInterface(device"net1:")
·EasyLANWirelessInterface(device"net1:")
Double
Serial
Interface
Board
"uart3:"
RS-232,
RS-422 non isolated,
or 20 mA current loop
"uart2:"
RS-232,
RS-422 non isolated,
RS-422 Isolated,
or RS-485
Serial/Industrial
Interface
Board
Industrial
interface
8 digital In ports
8 digital Out ports
4 relay ports
"uart2:"
RS-232,
RS-422 non isolated,
RS-422 Isolated,
or RS-485
Intermec
EasyCoder
PF4i
Compact
Industrial
—
User
’
s
Guide
(Fingerprint)
