Intermec EasyCoder PF4i - Cleaning the Media Guides

Chapter
11
—
Maintenance
Cleaning
the
Media
Guides
Bothpartsofthelabelstopsensor,whichcontrolsthemediafeed,are
coveredbyplasticguides.Theguidesaretransparenttoallowthelightto
passbetweenthetwopartsofthelabelstopsensor.Theseareas(indicated
byashadeofgrayinillustration#2below)mustbekeptcleanfromdust,
stucklabels,andadhesiveresidue.
Iftheprinterstartstofeedoutlabelsinanunexpectedway,raisethe
upperguideasdescribedbelowandcheckforanyobjectthatmayblock
thebeamoflight(dust,stucklabels,adhesiveresidue,etc.).Ifnecessary,
cleantheguidesusingacleaningcardorasoftclothsoakedwithiso-
propylalcohol.Donotuseanyothertypeofchemical.Becarefulnotto
scratchtheguides.
Isopropylalcohol[(CH3)2CHOH;CAS67-63-0]isahighly
fl
ammable,moderatelytoxic,andmildlyirritatingsub-
stance.
1
Lift
the
inner
part
of
the
upper
guide
and pull it outwards, disengaging it
from the lower guide. Take care not to
damage the cable.
