Intermec EasyCoder PF4i User Manual

Chapter
12
—
Adjustments
Ribbon
Break
Shaft
Ifribbonwrinklingoccurs,youmayneedtoadjustthealignmentofthe
frontribbonbreakshaftsothatitrunsparalleltotheprintheadandthe
ribbonsupplyandrewindhubs.Theadjustmentisdoneusingastraight-
slotscrewthatislocatedimmediatelybehindthefrontribbonbreak
shaft.
·Iftheribbontendstoslideoutwards,turnthescrewcarefullyclock-
wise(fw)tomovetheouterendofthebreakshaftforward.
·Iftheribbontendstoslideinwards,turnthescrewcarefullycounter-
clockwise(bw)tomovetheouterendofthebreakshaftbackward.
Beforereadjustingthebreakshaft,makesurethatthereis
noothercauseforthewrinklingoftheribbon.(SeeChap-
ter10,“Troubleshooting.”)
Adjustment
Screw
Ribbon
Break
Shaft
Intermec
EasyCoder
PF4i
Compact
Industrial
—
User
’
s
Guide
(Fingerprint)
