Chapter
2
—
Installation
Print
Mechanism
Theprintmechanismfeaturesahigh-performancethermalprinthead
withquick-mountfittingstofacilitatereplacement.
Thermal
printhead
Tear bar
(tear upwards)
Pressure arm
Tear bar
(tear downwards
and peel-off))
Platen roller
12
