Chapter
2
—
Installation
Media
Supply
Positions
Therearefoursetsofslotsandthreadedholesintheprinter’
scentersec-
tionforthemediasupplyrollpostorrotatinghub(optional).Theseslots
allowthelargestpossiblerollsizeto
fi
t,giventhelimitationsofanyliner
takeupunitand/orthefullenclosureprovidedbythelongsidedooror
Megatop.Thepositionsareindicatedbynumbersengravedinthecenter
section.
·Position1isusedwhenthemediacompartmentisfullyenclosedbya
longsidedoor,regardlessoftheexistenceofanyintegrallinertakeup
unit.Maximumrollsizeis152mm(6inches).
·Position2isnotused.
·Position3isusedwhentheprinterhasanintegrallinertakeupunit
andalongsidedoor.Thispositionisalsousedwiththe8-inch
Megatop.Maximumrollsizeis213mm(8.38inches).
·Position4isnotused.
Theprintercanalsouseanexternalmediasupplylocatedbehindthe
printer,exceptwhenithasan8-inchMegatop.
Position
3
Position
2
(not used)
Position
1
Position
4
(not used)
Intermec
EasyCoder
PF4i
Compact
Industrial
—
User
’
s
Guide
(Fingerprint)

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
