Ser-Com "uart1:"
Baudrate 9600bps
Characterlength 8bits
Parity None
Stopbits 1bit
RTS/CTS Disable
ENQ/ACK Disable
XON/XOFF,datatohost Disable
XON/XOFF,datafromhost Disable
Newline CR/LF
Receivebuffer 1024bytes
Transmitbuffer 1024bytes
Feedadjust:
Startadjust 0
Stopadjust 0
Media:
X-start(8dots/mm=203.2dpi) 24
X-start(11.81dots/mm=300dpi) 36(option)
Width(8dots/mm=203.2dpi) 832
Width(11.81dots/mm=300dpi) 1248(option
Length(8dots/mm=203.2dpi) 1200
Length(11.81dots/mm=300dpi) 1800(option
Mediatype Label(wGaps
Papertype Thermaltran
Ribbonconstant 90
Ribbonfactor 25
Labeloffset 0
Lowdiameter 0
Contrast ±0%
Print Defines:
Printspeed 100mm/sec.
Chapter
6
—
Setting
Up
the
Printer
Default
Setup
Theprinter
’
sdefaultsetupislistedbelow(assumingnooptionsinstalled):
Intermec
EasyCoder
PF4i
Compact
Industrial
—
User
’
s
Guide
(Fingerprint)

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
