Interroll MultiControl Instruction Manual

Troubleshooting
Version 3.0 (08/2018)
54 Translation of original instruction manual
No.
Short text
Comment
31
ApplErrErrorLogUpdate
Access error on the error log file
40
ApplErrPanellllMode
Change of mode not allowed
41
ApplErrPanelLedBlocked
Access to LED control not allowed
42
ApplErrInvalidApplConf
Invalid configuration of the application program
50
ApplErrDriveError1
Error RollerDrive 1
51
ApplErrDriveError2
Error RollerDrive 2
52
ApplErrDriveError3
Error RollerDrive 3
53
ApplErrDriveError4
Error RollerDrive 4
60
ApplErrStateTable
Error in the application program
61
ApplErrCtrlError1
Specific errors of the application program. The
errors of the ZPA / ZPA + programs are explained
in the supplementary document.
62
ApplErrCtrlError2
63
ApplErrCtrlError3
64
ApplErrCtrlError4
65
ApplErrCtrlError5
66
ApplErrCtrlError6
67
ApplErrCtrlError7
68
ApplErrCtrlError8
69
ApplErrStartProgram
Start of the application program not possible
70
ApplErrSysRestart
(Re-) start of the application program / system
71
ApplErrPowerFail
Voltage error: breakdown of the supply voltage
90
ApplErrTemperature
Temperature error: Temperature at brake chopper
resistor too high
91
ApplErrLowVoltage
Voltage error: Supply voltage (L1 or L2) too low
92
ApplErrHighVoltage
Voltage error: Supply voltage (L1 or L2) too high

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
